Copper Pneumatic Silencer Muffler M G PT 1/8'' 1/4'' 3/8'' 1/2'' 3/4'' 1'' Exhaust Silencer for Solenoid Valves

PSV Copper Pneumatic Silencer Muffler M G PT 1/8'' 1/4'' 3/8'' 1/2'' 3/4'' 1'' Exhaust Silencer for Solenoid Valves

PST Sintered Exhaust Copper Pneumatic Silencer Muffler 1/8 1/4 3/8 1/2 3/4 1 Exhaust Silencer

Copper Pneumatic Silencer Muffler M G PT 1/8'' 1/4'' 3/8'' 1/2'' 3/4'' 1'' Exhaust Silencer for Solenoid Valves


Availability:

Quantity:



Inquiry Add to Basket

Pneumatic silencers, also commonly referred to as pneumatic mufflers, are used to reduce the dynamic noise of pneumatic components or devices, it can be directly mounted on the port of components or equipment, compact size, easy to install, with good muffling effect.

Model:
PSV
Brand:
WAALPC
Code:
6806900000

Product Description

1. Brass material, pressure resistant and explosion proof, clear threads and smooth.

2. It can withstand larger and stronger air pressure, not disengaged, with good anechoic effect.

3. Exhaust port by installing muffler to reduce the exhaust speed and power, so as to achieve the effect of noise reduction.

4. It can be linked with solenoid valve manifolds, aluminum rows, cylinders, etc.

Technical Parameters

Fluid	Air
Noise Elimination	10
Operating Pressure Range	0~1.0Mpa
Negative Pressure	-100Kpa (10Torr)
Pressure Resistance	1.0Mpa
Operating Temperature Range	0~80℃
Material	Brass
Applicable Tube	PU and Nylon

M thread, G thread, PT(R.ZG) thread, also can be customized as requirement. Standard thread applied is PT(R.ZG) thread.

M5=M5*0.8 01=PT1/8 02=PT1/4 03=PT3/8 04=PT1/2 06=PT3/4 10=PT1


PST-M5	PST-04	PSV-M5	PSV-04	PSB-01	PSB-06	PSC-01	PSC-06	PSLW-01	PSLW-06	PSLB-01	PSLB-06
PST-01	PST-06	PSV-01	PSV-06	PSB-02	PSB-10	PSC-02	PSC-10	PSLW-02	PSLW-10	PSLB-02	PSLB-10
PST-02	PST-10	PSV-02	PSV-10	PSB-03		PSC-03		PSLW-03		PSLB-03
PST-03		PSV-03		PSB-04		PSC-04		PSLW-04		PSLB-04

Specification Download

WAALPC Silencers.pdf
