Air Pressure Reducing Valve Pressure Regulating Valve Large Diameter Lubricator QIU-08/10/15 Pneumatic Components Oil-water Seperator

Large Diameter Lubricator Air Pressure Reducing Valve Pneumatic Components Oil-water Seperator


Availability:

Quantity:



Inquiry Add to Basket

High-flow oil mist lubricators (such as QIU series) are designed for industrial systems requiring continuous, high-volume lubrication.

Model:
QIU-08
Brand:
WAALPC
Code:
8424200000

Product Description

1. High-Efficiency Lubrication

Large-Capacity Output: Delivers consistent oil mist to multiple lubrication points simultaneously, ideal for heavy-duty or high-speed machinery.

Precision Control: Adjustable oil mist density and flow rate to match specific equipment needs.

2. Enhanced Equipment Protection

Wear Reduction: Forms a uniform oil film on moving parts (e.g., bearings, gears, pistons) to minimize friction and mechanical wear.

Heat Dissipation: Helps cool high-speed components, preventing thermal stress and extending component lifespan.

3. Energy and Cost Savings

Reduced Lubricant Waste: Optimizes oil usage through precise mist distribution, lowering operational costs.

Lower Maintenance: Minimizes downtime and repair frequency by preventing premature equipment failure.

4. Flexibility and Compatibility

Wide Application Range: Compatible with pneumatic systems, compressors, conveyor systems, and more.

Centralized System Integration: Easily connects to automated lubrication systems for large-scale facilities.

Technical Parameters

ORDERING CODE

DATA SHEET

Type name	Air Regulator
Model	QIU-08	QIU-10	QIU-15	QIU-20	QIU-25	QIU-35	QIU-40	QIU-50
Port Size	1/4	3/8	1/2	3/4	1	1-1/4	1-1/2	2
Working medium	Air
Working pressure	0~1.0Mpa
Operating temperature range	5-60℃
Recommended Oil	Oil for turbine 1 ISOVG32
Material	Aluminium alloy+PC
Weight	500g	500g	500g	800g	800g	1300g	1300g	1300g
Oil Cup Capacity (ml)	400	400	400	700	700	700	700	700

STRUCTURE

Oil-Mist Separator

DIMENSION(MM)

Model	Port size	A	D	D1	L1	L2	L
QIU-08	1/4	90	70	88	114	69	220
QIU-10	3/8	90	70	88	88	69	220
QIU-15	1/2	90	70	88	88	69	220
QIU-20	3/4	115	90	110	151	74	250
QIU-25	1	115	90	110	151	74	250
QIU-35	1-1/4	130	90	110	163	60	270
QIU-40	1-1/2	130	90	110	163	60	270
QIU-50	2	130	90	110	163	60	270

Specification Download

High flow QIU lubricator.pdf
