GC600-25
WAALPC
8421299090
1. The drip oil structure adopts a gap sealing form, which makes the oil supply regulation more stable and reliable; 2. The oil supply adjustment ring can only rotate once, and the oil supply size is basically distributed in a linear pattern. The oil supply amount can be roughly calculated based on the position of the scale ring; 3. Can refuel without stopping gas; 4. The special structure of the drip nozzle creates negative pressure at the drip outlet, resulting in low fogging flow rate; 5. Fast and reliable fixed connection, asy to install and use; 6. Stable pressure regulation and high repeatability accuracy; 7. There are three drainage forms to choose from: manual, differential pressure, and automatic drainage; 8. Efficient water and solid particle removal function. |
Industrial Production
Automation Equipment
Mechanical Equipment
Food Industry
Medical and Health Care
Electronic Industry
Textile Machinery
Packaging Machinery
DATA SHEET
Model | GC200-06 | GC200-08 | GC300-08 | GC300-10 | GC300-15 | GC400-10 | GC400-15 | GC600-20 | GC600-25 |
Working Medium | Air | ||||||||
Port Size | PT1/8 | PT1/4 | PT1/4 | PT3/8 | PT1/2 | PT3/8 | PT1/2 | PT3/4 | PT1 |
Grade of Filtration | 40um or 5um | ||||||||
pressure regulating range | Automatic and different pressure drain: 0.15~0.9Mpa; Manual drain: 0.05~0.9Mpa | ||||||||
Pressure Resistance | 1.5MPa (215Psi) | ||||||||
Max. Opreating Pressure | 1.0MPa(145Psi) | ||||||||
Operating temperature range | -5~70℃ | ||||||||
Filter Cup Capacity | 10CC | 40CC | 80CC | 230CC | |||||
Lubricator Cup Capacity | 25CC | 75CC | 160CC | 380CC | |||||
Weight | 580g | 1300g | 2360g | 5550g | |||||
Recommended Oil | ISO VG32/equivalent oil |
STRUCTURE
Model | A | AB | BA | C | K | KA | KB | P | PA | PB | Q | |
GC300-08 | 188 | 72 | 41.5 | 188 | 6.5 | 64 | 9 | PT1/4 | 35 | 143 | G1/8 | |
GC300-10 | 188 | 72 | 41.5 | 188 | 6.5 | 64 | 9 | PT3/8 | 35 | 143 | G1/8 | |
GC300-15 | 188 | 72 | 41.5 | 188 | 6.5 | 64 | 9 | PT1/2 | 35 | 143 | G1/8 | |
GC400-10 | 248 | 89 | 50 | 216 | 8.5 | 84 | 12 | PT3/8 | 40 | 166.5 | G1/4 | |
GC400-15 | 248 | 89 | 50 | 216 | 8.5 | 84 | 12 | PT1/2 | 40 | 166.5 | G1/4 | |
GC600-20 | 309 | 118 | 70 | 282 | 11 | 105 | 16 | PT3/4 | 50 | 219 | G1/4 | |
GC600-25 | 309 | 118 | 70 | 282 | 11 | 105 | 16 | PT1 | 50 | 219 | G1/4 |
