Anti-Corrosion Throttle Valve Fittings One-Touch Quick Fittings for Pnuematic Fittings Tubes

PC PE PU PL PV PZ 04 06 08 10 Waal Anti-Corrosion Throttle Valve Fittings One-Touch Quick Fittings for Pnuematic Fittings Tubes

Anti-Corrosion Throttle Valve Fittings One-Touch Quick Fittings for Pnuematic Fittings Tubes


Size:	PC PE PL PU PV PZ
Availability:

Quantity:



Inquiry Add to Basket

The main function of pneumatic fittings is to connect pneumatic components to achieve quick connection and disconnection, thereby improving work efficiency;
Pneumatic fittings are used in various industrial automation equipment, mechanical equipment and process equipment widely.

Model:
PC PE PL PU PV PZ
Brand:
WAALPC
Code:
7307190000

Product Description

1.Quick pneumatic tube fiting forpneumatic tube systems.

2.Wide range of tube fiting models to meet all your needs in pneumatic tube systems.

3.Even after installation, the direction of the tube can be changed freely.

4.Nickel-Plated metal body ensures anti-corrosion and anti contar mination.

5.All R and NPT threads are precoats sealant.

6.All cylindrical threads are standard with O-ring seals.

Technical Parameters

SPECIFICATIONS

Fluid	Air, Vacuum
Operating Pressure Range	0~1.0Mpa
NegatIive Pressure	-100Kpa(10Torr)
Pressure Resistance	1.5Mpa
Operating Temperature Range	5~60℃
Applicable Tube	PU and Nylon

TUBE OUTER DIAMETER:MM

Metric Size
Code	4	5	6	7	8	9	10	11	12	13	14	15	16
TubeOuterDiameter:mm	Φ4	Φ5	Φ6	Φ7	Φ8	Φ9	Φ10	Φ11	Φ12	Φ13	Φ14	Φ15	Φ16

Inch Size
Code	5/32	3/16	1/4	5/16	3/8	1/2
TubeOulerDiameter:mm	Φ5/32	Φ3/16	Φ1/4	Φ5/16	Φ3/8	Φ1/2

Metric Size
Code	M5	M6	M8	M10	M12	M12A	M14	M16	M20
Thread Size	M5*0.8	M6*01	M8*1	M10*01	M12*1.25	M12*1.5	M14*1.5	H16*1.5	M20*1.5

Inch Size	55°Taper Tube Size					55°Straight Tube Size
Code	01	02	03	04	06	G01	G02	G03	G04	G06
ThreadSize	R1/8	R1/4	R3/8	R1/2	R3/4	G1/8	G1/4	G3/8	G1/2	G3/4

American Size	60°Taper Tube Size
Code	U10	N01	N02	N03	N04	N06
Thread Size	10-320NF	NPT1/8	NPT1/4	NPT3/8	NPT1/2	NPT3/4

PLASTIC QUICK FITTINGS

Quick fittings

Specification Download

Quick fittings.pdf

Superiority

Why choose us? What can we do for you?

♦ Founded in 2011 and professional experienced in the field of producing pneumatic products for over 13+ years.
♦ We have strong production capacity, over 100000 pcs/month.
♦We have rich experience for offering OEM/ODM service
♦ We have strict quality control process with quick response of after sales service.
♦ Management system certification : ISO9001,CE, ROHS
♦ We have 10+ technical experts for researching and developing.
♦ Sales network expands from domestic sales to all over the world.
